Product Highlights:
- Versatile: Type1/Type2/Tesla/GBT charging-gun optional
- Wall-mounted or pole-mounted installation
- For home and commercial use
- Multiple safety protections
- IP65 weatherproof enclosure
- Communications: WIFI/Ethernet/4G/OCPP, flexible charging schedule
Adjustable Current | 32A | 16A 3Phase | 32A 3Phase |
Power | 7kW | 11kW | 22kW |
Voltage | 220-250V | AC380-480V | AC380V-480V |
Charging Connector | Type2 plug+5m cable or customize | Type2 plug+5m cable or customize | Type2 plug+5m cable or customize |
RCD | 30mA for AC faults (Type A ) or 30mA for AC and 6mA for DC faults (Type A + 6) | ||
User Interface | LED indicator, LCD display(4.3inch) | ||
Standard | IEC 62196-2 | ||
Connectivity | APP/RFID/PLAY-and-PLUG/4G | ||
Insatllation | Wall-mounted/ Pole-mounted | ||
Certifications | CE, RoHS, TUV | ||
Product Dimension | Control box: 230X92X310mm | ||
Protection Grade | Charging plug: IP65 Control box: IP65 | ||
Operating Temperature | -30°C to 50°C | ||
Performance and Safety | Over voltage protection, Under voltage protection, Over load protection, Leakage protection, Ground protection, Over temperature protection (85°C), Lightning protection, Short circuit protection, Flame retardant. | ||
